Predator Light Bar Wiring Harness | 14AWG Single-Output

The Salty Captain 14AWG Light Bar Harness is the only choice for powering large-scale LED bars. When you’re drawing up to 240W, thin wires just won't cut it - you need a heavy-gauge loom that can handle the heat.

• 14AWG Power Authority: The thicker 14-gauge wire reduces electrical resistance, allowing your light bar to run at its true potential. This ensures you get every single lumen you paid for, without the dimming or heat buildup associated with inferior 18AWG looms.
• Overbuilt for Off-Road: Every component is selected for durability. The 40A relay is housed in a moisture-resistant casing, and the entire length of the harness is wrapped in a protective conduit to prevent rubbing and fraying against the chassis or engine bay.
• Salty-Proof Connections: Featuring high-quality DT-style waterproof connectors with internal silicone seals, this harness is built for the beach. It locks out salt spray, mud, and dust, preventing the terminal corrosion that kills most 12V setups.
• Safe & Simple Install: This is a true "one-and-done" installation. With pre-terminated battery ring terminals and a pre-wired cabin switch, you can have your main light bar powered up and trail-ready in minutes.

• (1) Single-Output 14AWG Heavy-Duty Harness
• (1) 40A Waterproof Relay (Pre-installed)
• (1) 30A In-line Fuse (Pre-installed)
• (1) Illuminated LED Cabin Switch
• (1) Waterproof DT-Style Connector

• Cable Gauge: 14AWG (Heavy-Duty High-Current Copper)
• Configuration: Single-Output (Controls 1 Light Bar)
• Voltage Compatibility: 12V DC
• Relay: 40A Heavy-Duty Waterproof Relay
• Protection: 30A In-line Blade Fuse with Waterproof Cover
• Switch: Illuminated LED Rocker Switch
• Connectors: Heavy-Duty DT-Style (Deutsch) Waterproof Plug
• Insulation: Heat-Resistant Corrugated Conduit Wrap

Q: Why do I need 14AWG instead of the standard 18AWG?
A: Large light bars (32” and 42”) draw significant current. 18AWG is too thin for these loads and can cause the wire to heat up and the light to lose brightness. 14AWG is the professional standard for safety and maximum output.

Q: Can I use this for the 42” StormBar?
A: Absolutely. This harness is the recommended setup for our 42” bars, providing the heavy-duty circuit required for a 240W power draw.

Q: Is the switch illuminated?
A: Yes. The included rocker switch features a built-in LED that glows when the light is active, making it easy to find on the dash during pitch-black night drives.

Q: How long is the harness?
A: The loom provides ample length (approx. 3 metres) to run from your battery, through the firewall to the dash, and out to your bull bar or the base of your roof rack.
